Ultrasonic Bath Sonicator
Description
Technical Parameters
Key Features
Equipped with new software and centralized microcomputer control system
7-inch TFT touch screen display for intuitive operation
Ultrasonic power continuously adjustable in 1% increments
Supports pulse operation, continuous operation, and test function
Precise time control: ultrasonic time, interval time, and total time adjustable to 0.1 seconds
JY98-IIIN / JY98-IIIDN / JY99-IIDN Ultrasonic Homogenizers
Main Technical Parameters
| Parameter | JY98-IIIN | JY98-IIIDN | JY99-IIDN |
|---|---|---|---|
| Frequency | 19.5-20.5 KHz | 19.5-20.5 KHz | 19.5-20.5 KHz |
| Display | 7-inch TFT touch screen | 7-inch TFT touch screen | 7-inch TFT touch screen |
| Adjustable Power Range | 1200 W (20%-99%) | 1200 W (20%-99%) | 1800 W (20%-99%) |
| Standard Tip | 20 mm | 20 mm | 25 mm |
| Optional Tips | 15 mm, 25 mm | 15 mm, 25 mm | 20 mm, 28 mm |
| Processing Volume | 50-1000 ml | 50-1000 ml | 50-1200 ml |
| Duty Ratio | 1-99% | 0.1-99.9% | 0.1-99.9% |
| Temperature Alarm | No | Yes (Prevents sample overheating) | Yes (Prevents sample overheating) |
| Alarm Functions | Over-temperature, overtime, overload protection | Over-temperature, overtime, overload protection | Over-temperature, overtime, overload protection |
| Power Supply Chassis Dimensions (L×W×H) | 430×255×300 mm | 430×255×300 mm | 430×255×300 mm |
| Net Weight (Power Supply) | 12.1 Kg | 12.1 Kg | 13 Kg |
| Total Weight (Host + Transducer) | 14.5 Kg | 14.5 Kg | 15 Kg |
| Soundproof Enclosure Dimensions (L×W×H) | 345×340×570 mm | 345×340×570 mm | 345×340×570 mm |
Format Notes
Packaging & Shipping
Delivery detail:
UPS/DHL/FEDEX/TNT express are available for your choose which take 3~ 5 days to arrive,and we will offer the tracking number for you to check the status of your items online at any time.
By air cargo which takes about one week to arrive .
By sea which takes about 20-30days to arrive , depending on your actual requirements.
Our Services
1.Warranty:
12 months warranty for scientz ultrasonic homogenizer.
If any technical problem during warranty time, replacement parts will be sent free of charge.
Technical support is also available in whole time.
2.Our Advantage
1. Reply your enquiry in 24 working hours.
2. Experienced staffs answer all your questions in fluent English.
3. OEM is available if the quantity is large.
4. We offer very competitive for all our products.
3.After-sales
Our machines undergo an extensive and strict testing and quality control procedure, ensuring every item purchased meet global quality standards.It's safe and reliable quality for ultrasonic homogenizer.
