JY96-IIN Ultrasonic Homogenizer
Description
Technical Parameters
Ningbo Scientz Biotechnology Co.,Ltd. is one of the leading jy96-iin ultrasonic homogenizer suppliers in China. Welcome to buy our quality and cheap products for sale in bulk. We also welcome wholesale orders and customized orders. Now, please be free to check the price list with our factory.
JY96-IIN ultrasonic homogenizer
JY96-IIN ultrasonic homogenizer, adjustable power 5%~99%, can handle 10~100ml samples. It can handle the crushing of many kinds of cells, bacteria, viruses and animal and plant tissues, and can prepare, disperse and accelerate chemical reactions. Applied in biology, medicine, agronomy, chemistry, material science, pharmaceuticals, etc.
Adjustable power
Processing Volume
10～100ml
Titanium tips
standard 6mm
Electric lifting table
Working Principle
Based on the cavitation effect of ultrasound in liquids, the transducer transfers electrical energy Through the amplitude-variable rod in the liquid at the top of the tool head to produce high-intensity shear force the formation of high-frequency alternating water pressure intensity so that the cavity expansion, explosion will be broken cells. in addition,the use of ultrasonic propagation in the liquid to produce violent perturbation effect, so that the particles produce a large acceleration.thus colliding with each other or collision with the wall to achieve theeffect of crushing, emulsification and separation.
Features
JY96-IIN ultrasonic homogenizer
Low sample loss
Capable of handling as little as 10ml and up to 100 ml
Flexible parameters
Adjustable power150 W(1%-100%)
Frequency(20～25KHz)
Empty Occupation Ratio(0.1～99.9%)
Alarm Temperature(0～99.9℃)
transducer
TC4 transducer(optional)
Electric lifting table
7-inch touch screen
Titanium tip
standard
Application
Bioengineering
01
Biopharmaceuticals
02
Foodstuffs Engineering
03
Environmental Project
04
- Disruption of cells, bacteria, viruses, spores, and other cell structures.
- Ultrasonic homogenization of beverages
- Maturation and aging acceleration techniques for wine
-
Accelerating
dissolution and chemical reactions, such as in fat processing.
- Dispersion of pharmaceutical substances for injection - Homogenization of soil and rock samples
- Study of the structural and physical characteristics of rocks.
- Dispersion of pharmaceutical substances for injection.
- Dispersion and extraction of traditional Chinese medicines.
-
Disruption, emulsification, homogenization, and fragmentation of particles like carbon nanotubes and
rare earth materials.
Hot Tags: jy96-iin ultrasonic homogenizer, China, factory, suppliers, wholesale, customized, buy, cheap, bulk, price list, for sale
comparison of product parameters
Note: Standard equipped with Titanium tips.
| Model | JY96-IIN |
| Power range | 150W adjustable |
| Frequency | 20-25kHz self-adaptive |
| Processing volume | 10ml ～ 100ml |
| Timing | 1 ～ 999min |
| Temperature Alarm | 0℃～ 99℃ |
| Display | Amplitude, power, temperature, time |
| Alarm |
Over-temperature, overload, time |
|
Empty Occupation Ratio |
0.1～99.9% |
|
Standard |
Φ6mm |
| Optional horn |
Φ3 mm |
